Fire Hose Reel - Swing Arm - 19mm x 36m

Swing arm fire hose reel with 19mm hose, 36 metres long - complete with fitting kit and valves, ideal for use in cabinets / cupboards
Manufacturer: Varies
Availability: In stock
$300.00 excl GST
Ship to
Shipping Method
Estimated Delivery
No shipping options

This standard swing arm fire hose reel has a 19mm x 36m long hose and is supplied with all valves and fittings required for installation. Having a swing arm makes it ideal for use when mounted in cupboards or cabinets.


Class A fires – Ordinary combustibles

Installation and location:-

The location of the fire hose reel is determined by the Building Codes of Australia (BCA). Fire hose reels are specified and positioned prior to building plans being approved.
This fire hose reel must be installed in accordance with AS2441:2005


The fire hose reel is designed to be a quick fit hose reel, ideal for new installations and also for replacing existing fire hose reels. To replace the fire hose reel, the fire water line to the building will have to be located and isolated to allow the fire hose reels to be exchanged, although this is not a complicated operation it is advisable to enlist the services of a qualified plumber to complete this operation.

Type Swing arm fire hose reel
Hose Size 19mm diameter hose, 36m long
Floor area Up to 250m2 (in accordance with AS2444:2001)*
Nozzle Type Brass twist type nozzle
Nominal Inlet Pressure 220kpa (2.2bar / 32psi) at 23 Deg C
Tested Pressure 1700pa (17bar / 247psi)
Approvals Certified and approved to AS/NZS 1221 (1997)
Appearance Red with a white usage plate in centre. Black hose.
- Width
- Height
- Depth
- Weight

As Packaged
- Length
- Width
- Height
- Weight


When you buy this fire hose reel, you receive the following items included in the price:-

  • Maintenance tag
  • Maintenance tag ring
  • Fire Hose Reel location sign - SGHRL
  • All Valves, connections and brackets - including 36m of 19mm hose and a fitted brass nozzle.

We do not supply wall fixings with this fire hose reel.

While every effort is made to ensure the specifications and pictures are correct, we source products from a number of manufacturers, which leads to differences both visually and physically between equivalent products. If you need current up to date specifications, please Contact Us
